SmallHD Ultrabright 5″ LCD Monitor

Description

Powerful, portable, and adaptable, the Ultra 5 offers 3000nits of dazzling brightness, a locking power adaptor, an Ethernet port for camera control, plus a full suite of large, front- facing physical buttons for maximum control in all conditions. Experience all your favorite PageOS 5
tools, functions, and settings pages on a fully-  loaded 5-inch touchscreen monitor.

• 2 pin Lemo Cable
• No HDMI nor Monitor hood

Display
Display 5″ / 17.8 cm IPS LCD
Resolution 1920 x 1080
Pixel Density 443 PPI
Aspect Ratio 16:9
Brightness 2200 cd/m²
Contrast Ratio 1000:1
Color Gamut 70% NTSC
Bit Depth 10-bit
Viewing Angle 178°
Backlight White LED (adjustable)
Temperature Adaptive Color Not specified by the manufacturer

Technical
Inputs 1 x BNC, SD/HD/3G-SDI
1 x HDMI Type A
Outputs 1 x BNC, SD/HD/3G-SDI (also functions as secondary input)
1 x HDMI Type A
1 x 3.5 mm stereo headphone
Input Signal SDI: 10-bit YCC 4:2:2
1080p 23.98/24/25/29.97/30/50/59.94/60
1080PsF 23.98/24/25/29.97/30
1080i 50/59.94/60
720p 23.98/24/25/29.97/30/50/59.94/60
NTSC
PAL

HDMI: 8/10/12-bit color
1080p 23.98/24/25/30/50/59.94/60
1080PsF 23.98/24/25/30
1080i 50/59.94/60
720p 23.98/24/25/30/50/59.94/60 (high-speed: 720p 100/119.88/120)
576p 50 (high-speed: 576p 100)
480p 59.94/60 (high-speed: 480p 119.88/120)
NTSC (high-speed: 480i 119.88/120/239.76/240)
PAL (high-speed: 576i 100/200)

Audio:
HDMI and SDI embedded
Output Signal SDI: 10-bit YCC 4:2:2
1080p 23.98/24/25/29.97/30/50/59.94/60
1080PsF 23.98/24/25/29.97/30
1080i 50/59.94/60
720p 23.98/24/25/29.97/30/50/59.94/60
NTSC
PAL

HDMI: 8/10/12-bit color
1080p 23.98/24/25/30/50/59.94/60
1080PsF 23.98/24/25/30
1080i 50/59.94/60
720p 23.98/24/25/30/50/59.94/60 (high-speed: 720p 100/119.88/120)
576p 50 (high-speed: 576p 100)
480p 59.94/60 (high-speed: 480p 119.88/120)
NTSC (high-speed: 480i 119.88/120/239.76/240)
PAL (high-speed: 576i 100/200)

Audio:
HDMI and SDI embedded

General
Power Input: 1 x 2-pin LEMO
Output: 1 x 2-pin LEMO

Voltage:
DV Battery Plate: 6-8.4 VDC (7.2 VDC nominal)
High Voltage Battery Plate: 12-34 VDC (14.4 VDC nominal)

Consumption: 11 W
Storage SD card slot
Compliance FCC, IC, CE, RoHS
Screen Protection Bonded Gorilla Glass
Mount Type 3 x 1/4″-20 threaded holes (bottom, top, and back)
Environmental Operating Temperature: 0 to 100°F / -17.8 to 37.8°C
Storage Temperature: -4 to 120°F / -20 to 48.9°C
Dimensions 3.4 x 6.2 x 1.1″ / 8.5 x 15.7 x 2.9 cm
Weight 15 oz / 431 g (without battery)
